<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 本套工頻無局部放電試驗變壓器主要用于</span><span style="font-family:微軟雅黑">35kV及以下產品工頻耐壓及局部</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑">放電試驗。現場主要用于高壓互感器局放試驗、高壓環氧柜局放試驗、高壓開關</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑">柜耐壓試驗、電力變壓器耐壓試驗、高壓斷路器耐壓試驗、避雷器局放試驗等。</span></p><p class="MsoNormal"><strong>產品參數</strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定容量：</span><span style="font-family:微軟雅黑">50kVA</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定電壓：</span><span style="font-family:微軟雅黑">150kV</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 輸入電壓：</span><span style="font-family:微軟雅黑">380V</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 阻抗電壓：</span><span style="font-family:微軟雅黑"><10%</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 局部放電量：</span><span style="font-family:微軟雅黑"><5PC</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 測量精度：</span><span style="font-family:微軟雅黑">1%</span></p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 10kV電力變壓器工頻耐壓試驗</p><p class="MsoNormal"> 10kV電流互感器工頻耐壓和局部放電試驗</p><p class="MsoNormal"> 10kV高壓開關柜工頻耐壓試驗</p><p class="MsoNormal"> 10kV環氧柜工頻耐壓和局部放電試驗</p><p class="MsoNormal"> 10kV避雷器局部放電試驗</p><p class="MsoNormal"> 10kV高壓斷路器耐壓試驗</p>
<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 本套工頻無局部放電試驗變壓器主要用于</span><span style="font-family:微軟雅黑">35kV及以下產品工頻耐壓及局部</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑">放電試驗。現場主要用于高壓互感器局放試驗、高壓環氧柜局放試驗、高壓開關</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑">柜耐壓試驗、電力變壓器耐壓試驗、高壓斷路器耐壓試驗、避雷器局放試驗等。</span></p><p class="MsoNormal"><strong>產品參數</strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定容量：</span><span style="font-family:微軟雅黑">75kVA</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定電壓：</span><span style="font-family:微軟雅黑">150kV</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 輸入電壓：</span><span style="font-family:微軟雅黑">380V</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 阻抗電壓：</span><span style="font-family:微軟雅黑"><10%</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 局部局放量：</span><span style="font-family:微軟雅黑"><5PC</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 測量精度：</span><span style="font-family:微軟雅黑">1%</span></p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 10kV電力變壓器工頻耐壓試驗</p><p class="MsoNormal"> 10kV電流互感器工頻耐壓試驗</p><p class="MsoNormal"> 10kV高壓開關柜工頻耐壓試驗</p><p class="MsoNormal"> 10kV環氧柜工頻耐壓試驗</p><p class="MsoNormal"> 10kV高壓斷路器耐壓試驗</p>
<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 本套沖擊電壓發生器主要用于</span><span style="font-family:微軟雅黑">35kV及以下產品雷電波和截波及操作波。現場主</span>要用于高壓互感器雷電波試驗、高壓環氧柜雷電波試驗、高壓開關柜雷電波試驗、電力變壓器雷電波和截波試驗、高壓斷路器雷電波試驗等。</p><p class="p"><strong><span class="15">產品參數</span></strong><strong><span class="15"></span></strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定電壓：</span><span style="font-family:微軟雅黑">400kV</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 級電壓：</span><span style="font-family:微軟雅黑">100kV</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定能量：</span><span style="font-family:微軟雅黑">20kJ</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 級能量：</span><span style="font-family:微軟雅黑">5kJ</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 主電容量：</span><span style="font-family:微軟雅黑">0.25uF</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 級電容量：</span><span style="font-family:微軟雅黑">1uF</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 級數：</span><span style="font-family:微軟雅黑">4級</span></p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 10kV柱上開關雷電沖擊電壓試驗</p><p class="MsoNormal"> 10kV環氧柜雷電沖擊電壓試驗</p><p class="MsoNormal"> 10kV斷路器雷電沖擊電壓試驗</p><p class="MsoNormal"> 35kV斷路器雷電沖擊電壓試驗</p><p class="MsoNormal"> 10kV高壓開關柜雷電沖擊電壓試驗</p><p class="MsoNormal"> 10kV電壓、電流互感器雷電沖擊電壓試驗</p><p class="MsoNormal"> 10kV電力變壓器雷電沖擊電壓和截波試驗</p>
<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"> 本套截波裝置主要用于35kV及以下產品截波試驗。現場主要用于電力變壓器截波試驗以及線圈類產品截波試驗。</p><p class="MsoNormal"><strong><span class="15"><span style="font-family:微軟雅黑">產品參數</span></span></strong><strong><span class="15"></span></strong></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 額定電壓：</span><span style="font-family:微軟雅黑">300kV</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 級電壓：</span><span style="font-family:微軟雅黑">150</span></span><span class="15"><span style="font-family:微軟雅黑">kV</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 電容量：</span><span style="font-family:微軟雅黑">300pF</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 級數：</span><span style="font-family:微軟雅黑">2級</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 最大行程：</span><span style="font-family:微軟雅黑">70mm</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 截斷時間：</span></span><span class="15"><span style="font-family:微軟雅黑">2-6</span></span><span class="15"><span style="font-family:微軟雅黑">u</span></span><span class="15"><span style="font-family:微軟雅黑">s</span></span><span class="15"></span></p><p class="MsoNormal"><strong><span class="15"><span style="font-family:微軟雅黑">產品現場完成項目</span></span></strong><strong><span class="15"></span></strong></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 10kV電力變壓器雷電截波試驗</span></span><span class="15"></span></p>
<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"> 本套陡化裝置主要用于高壓線路B型線路絕緣子和高壓線路有機復合絕緣子等產品的陡波沖擊電壓試驗。</p><p class="MsoNormal"><strong><span class="15"><span style="font-family:微軟雅黑">產品參數</span></span></strong><strong><span class="15"></span></strong></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 額定電壓</span><span style="font-family:微軟雅黑">600kV</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 電容量：</span><span style="font-family:微軟雅黑">300pF</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 電阻量：</span><span style="font-family:微軟雅黑">2.5K</span></span><span class="15"><span style="font-family:宋體">Ω</span></span><span class="15"> </span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 球經：</span><span style="font-family:微軟雅黑">150mm</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 行程距離：0~</span><span style="font-family:微軟雅黑">180mm</span></span><span class="15"></span></p><p class="MsoNormal"><strong><span class="15"><span style="font-family:微軟雅黑">產品現場完成項目</span></span></strong><strong><span class="15"></span></strong></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 有機復合絕緣子陡波試驗</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 瓷絕緣子陡波試驗</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 玻璃絕緣子陡波試驗</span></span><span class="15"></span></p><p class="MsoNormal"><span class="15"><span style="font-family:微軟雅黑"> 柱式復合絕緣子陡波試驗</span></span><span class="15"></span></p>
<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"> 本套感應試驗裝置主要用于10kV干式電力變壓器感應耐壓及局部放電試驗。</p><p class="MsoNormal"><strong>產品參數</strong></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 輸出電壓：</span><span style="font-family:微軟雅黑">0.8kV</span></p><p class="MsoNormal"> 輸出頻率：100HZ/150HZ/200HZ</p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 電容量：</span><span style="font-family:微軟雅黑">300PF</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定電壓：</span><span style="font-family:微軟雅黑">100</span>kV</p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 局部放電量：</span><span style="font-family:微軟雅黑">≤5pC</span></p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 10kV干式電力變壓器感應耐壓及局放試驗</p><p class="MsoNormal"> 10kV電力變壓器感應耐壓試驗</p>
<p class="MsoNormal"><strong>產品用途</strong></p><p class="MsoNormal"> 本套三相溫升大電流發生器主要用于母線槽、開關、開關柜和其它電器設備作電流負載試驗及溫升試驗。</p><p class="MsoNormal"><strong>產品參數</strong></p><p class="15"> 額定容量：15KVA <span style="font-family:微軟雅黑">6</span>KVA</p><p class="15"> 相數：三相或單相</p><p class="15"><span style="font-family:微軟雅黑"> 輸入電流：</span><span style="font-family:微軟雅黑">AC 0 ～ 1</span>8.4A</p><p class="15"><span style="font-family:微軟雅黑"> 輸出電壓：</span><span style="font-family:微軟雅黑">AC 0 ～</span>10V</p><p class="15"> 輸出電流：0 ～ 1500A AC 0 ～600A</p><p class="15"><span style="font-family:微軟雅黑"> 電壓測量精度：</span><span style="font-family:微軟雅黑">0.5 ％</span></p><p class="15"><span style="font-family:微軟雅黑"> 電流測量精度：</span><span style="font-family:微軟雅黑">0.5 ％</span></p><p class="15"><span style="font-family:微軟雅黑"> 計時長度：</span><span style="font-family:微軟雅黑">0 ～ 999S</span></p><p class="15"> 溫度采集：40組溫度同時采集并且可生成溫度曲線圖</p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 母線槽溫升試驗</p>
<p class="p"><strong>產品用途</strong></p><p class="p"> 本套<span style="font-family:微軟雅黑">調頻串聯諧振試驗裝置主要用于</span><span style="font-family:微軟雅黑">GIS組合電器以及電</span>力電纜等其它大電容量電力設備的現場交流耐壓試驗及局放試驗。</p><p class="MsoNormal"><strong>產品參數</strong></p><p class="MsoNormal"> 額定容量：5250kVA</p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定電壓：</span><span style="font-family:微軟雅黑">750kV</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 額定電流：</span><span style="font-family:微軟雅黑">7A</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 頻率可調范圍：</span><span style="font-family:微軟雅黑">30~300HZ</span></p><p class="MsoNormal"> 頻率分辨率：0.1Hz</p><p class="MsoNormal"> 頻率不穩定度：≤0.05％</p><p class="MsoNormal"> 電壓波形：正弧波</p><p class="p"> 電壓波形畸變率：≤1.0％</p><p class="p"> 噪聲水平：≤85dB</p><p class="p"> 局部放電量：≤10PC </p><p class="p"><span style="font-family:微軟雅黑"> 品質因數：</span><span style="font-family:微軟雅黑">Q>50</span></p><p class="MsoNormal"> 絕緣水平：1.1倍額定電壓下耐壓１min</p><p class="MsoNormal"> 運行時間：<span style="font-family:微軟雅黑">額定輸出電流下允許運行時間</span><span style="font-family:微軟雅黑">1小時開1小時關，一天3次循環</span></p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 允許溫升：在額定容量下，線圈溫升</span><span style="font-family:微軟雅黑">≤65K</span></p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 500kV GIS現場耐壓及局部放電試驗</p><p class="MsoNormal"> 500kV電力電纜現場耐壓及局部放電試驗</p>
<p class="MsoNormal"><strong>產品特點</strong></p><p class="MsoNormal"> 本套無局放變頻電源主要用于電氣設備的交流耐壓試驗和局部放電試驗。通過利用勵磁變壓器激發串聯或并聯諧振裝置<span style="font-family:微軟雅黑">回路，調節變頻電源的輸出頻率，使得回路中的電抗器電感</span><span style="font-family:微軟雅黑">L和試品電容C發生諧振，</span>產生試品上所需加電壓；或通過中間變壓器直接輸出至變壓器初級進行感應耐壓試驗。</p><p class="MsoNormal"><strong>產品參數</strong></p><p class="MsoNormal"> 額定容量：150kW</p><p class="MsoNormal"><span style="font-family:微軟雅黑"> 輸入電壓：三相</span><span style="font-family:微軟雅黑">380V</span>±15％</p><p class="MsoNormal"> 輸出電壓：<span style="font-family:微軟雅黑">單相</span><span style="font-family:微軟雅黑">0～350V</span>或三相0～900V</p><p class="MsoNormal"> 頻率范圍：30～300Hz</p><p class="MsoNormal"> 電壓穩定性：±1％</p><p class="MsoNormal"> 頻率穩定性：±0.1％</p><p class="MsoNormal"> 頻率分辨率：≤0.1Hz</p><p class="MsoNormal"> 電壓波形畸變率：<3％</p><p class="MsoNormal"> 噪聲：≤85dB</p><p class="MsoNormal"> 冷卻方式：強迫風冷</p><p class="MsoNormal"><strong>產品現場完成項目</strong></p><p class="MsoNormal"> 500kV GIS現場耐壓及局部放電試驗</p><p class="MsoNormal"> 500kV電力電纜現場耐壓及局部放電試驗</p><p class="MsoNormal"> 10kV干式變壓器感應耐壓及局部放電試驗</p><p class="MsoNormal"> </p>
<p style="text-autospace:ideograph-numeric;line-height:27px"><strong><span style="font-family: 微軟雅黑;font-size: 20px">產品用途</span></strong></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">本套阻容分壓器主要用于電力系統電力、電子設備制造部門測量工頻交流高電壓、直流高電壓、沖擊雷電波、操作波等高壓測量。</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><br/></span></p><p style="text-autospace:ideograph-numeric;line-height:27px"><strong><span style="font-family: 微軟雅黑;font-size: 20px">產品特點</span></strong></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">本套阻容分壓器精密高壓電容和精密高壓玻璃釉電阻，輸入阻抗高，降低測試電流。</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">本套阻容分壓器功耗小，測量精度高和穩定性好。</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">本套阻容分壓器采用特殊屏蔽技術，抗干擾能力強。</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">本套阻容分壓器用途多樣化，工頻交流電壓、直流電壓、雷電沖擊等測量。</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><br/></span></p><p style="text-autospace:ideograph-numeric;line-height:27px"><strong><span style="font-family: 微軟雅黑;font-size: 20px">產品參數</span></strong></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><span style="font-family:微軟雅黑">額定交流電壓：</span><span style="font-family:微軟雅黑">0~1500kV</span></span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><span style="font-family:微軟雅黑">額定直流電壓：0~</span></span><span style=";font-family:微軟雅黑;font-size:16px">±1800kV</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><span style="font-family:微軟雅黑">額定沖擊雷電波：</span><span style="font-family:微軟雅黑">0~±3600kV</span></span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><span style="font-family:微軟雅黑">額定沖擊操作波：</span><span style="font-family:微軟雅黑">0~±2500kV</span></span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px"><span style="font-family:微軟雅黑"><br/></span></span></p><p style="text-autospace:ideograph-numeric;line-height:27px"><strong><span style="font-family: 微軟雅黑;font-size: 20px">產品現場完成項目</span></strong></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">現場工頻交流試驗</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">現場直流試驗</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">現場沖擊雷電波試驗</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">現場沖擊操作波試驗</span></p><p style="text-indent:32px;text-autospace:ideograph-numeric;line-height:27px"><span style=";font-family:微軟雅黑;font-size:16px">現場聯合試驗</span></p><p><br/></p>
